HF
FLAILY Hammer mowers
with no swing disk
Flaily is available in different working widths, from 1.00 m to 2.10 m, making it flexible and adaptable to different agricultural requirements.
Flaily standard version has the gearbox positioned very low, to keep the machine close to the ground. This is particularly important just before vintage, when it is essential not to damage grapes.
The large number of double sided blades, which rotate at over 2.100 revs/min cut grass and shoots in very small pieces. The roller on the rear, adjustable in height, can be adapted to any situation. Thanks to the side runners, Flaily is perfect for the
maintenance of grassy surfaces, even on steep terrain.
Flaily machines can also combine cutting with weeding; on request they can be fitted with the Herbymulching system, with significant economical advantages in terms of hectare/hour and fuel consumption.
TECHNICAL DATA: SELECT THE MODEL
| Working width | cm 95 |
| Number of EM80 double sided blades | 28 |
| Maximum diameter of light wood | cm 1 |
| 3 point linkage ISO | I/II |
| Number of belts | 3 |
| Diameter of height adjustable roller | cm 133 |
| Side shift from middle of tractor | cm 63 |
| HP | CV 10 |
| Hydraulic side shift | n.d. |
| Mechanic side shift | n.d. |
| Angle gear positioned low | S |
| Angle gear 540 revs/min-1 with freewheel | S |
| Groupe multiplicateur 1000 tours /min-1 avec roue libre | n.d. |
| Front version for front PTO 540/1.000 revs/min-1 | n.d. |
| Side runners adjustable in height | O |
| Herbymulching: 100 lt herbicide tank with 12V pump | n.d. |
| Herbymulching: 200 lt herbicide tank with 12V pump | n.d. |
| Overall size - Length | cm 114 |
| Weight (standard version) | kg 380 |
O=Optional - nd=Not available - S=Standard
Download pdf FL 1000
| Working width | cm 115 |
| Number of EM80 double sided blades | 36 |
| Maximum diameter of light wood | cm 1 |
| 3 point linkage ISO | I/II |
| Number of belts | 3 |
| Diameter of height adjustable roller | cm 133 |
| Side shift from middle of tractor | cm 87 |
| HP | CV 15 |
| Hydraulic side shift | O |
| Mechanic side shift | S |
| Angle gear positioned low | S |
| Angle gear 540 revs/min-1 with freewheel | S |
| Groupe multiplicateur 1000 tours /min-1 avec roue libre | n.d. |
| Front version for front PTO 540/1.000 revs/min-1 | n.d. |
| Side runners adjustable in height | O |
| Herbymulching: 100 lt herbicide tank with 12V pump | O |
| Herbymulching: 200 lt herbicide tank with 12V pump | n.d. |
| Overall size - Length | cm 134 |
| Weight (standard version) | kg 400 |
O=Optional - nd=Not available - S=Standard
Download pdf FL 1200
| Working width | cm 135 |
| Number of EM80 double sided blades | 44 |
| Maximum diameter of light wood | cm 1 |
| 3 point linkage ISO | I/II |
| Number of belts | 4 |
| Diameter of height adjustable roller | cm 133 |
| Side shift from middle of tractor | cm 103 |
| HP | CV 18 |
| Hydraulic side shift | O |
| Mechanic side shift | S |
| Angle gear positioned low | S |
| Angle gear 540 revs/min-1 with freewheel | S |
| Groupe multiplicateur 1000 tours /min-1 avec roue libre | n.d. |
| Front version for front PTO 540/1.000 revs/min-1 | n.d. |
| Side runners adjustable in height | O |
| Herbymulching: 100 lt herbicide tank with 12V pump | O |
| Herbymulching: 200 lt herbicide tank with 12V pump | O |
| Overall size - Length | cm 155 |
| Weight (standard version) | kg 450 |
O=Optional - nd=Not available - S=Standard
Download pdf FL 1400
| Working width | cm 155 |
| Number of EM80 double sided blades | 52 |
| Maximum diameter of light wood | cm 1 |
| 3 point linkage ISO | I/II |
| Number of belts | 4 |
| Diameter of height adjustable roller | cm 133 |
| Side shift from middle of tractor | cm 176 |
| HP | CV 20 |
| Hydraulic side shift | O |
| Mechanic side shift | S |
| Angle gear positioned low | S |
| Angle gear 540 revs/min-1 with freewheel | S |
| Groupe multiplicateur 1000 tours /min-1 avec roue libre | n.d. |
| Front version for front PTO 540/1.000 revs/min-1 | n.d. |
| Side runners adjustable in height | O |
| Herbymulching: 100 lt herbicide tank with 12V pump | O |
| Herbymulching: 200 lt herbicide tank with 12V pump | O |
| Overall size - Length | cm 176 |
| Weight (standard version) | kg 490 |
O=Optional - nd=Not available - S=Standard
Download pdf FL 1600
| Working width | cm 175 |
| Number of EM80 double sided blades | 60 |
| Maximum diameter of light wood | cm 1 |
| 3 point linkage ISO | I/II |
| Number of belts | 4 |
| Diameter of height adjustable roller | cm 133 |
| Side shift from middle of tractor | cm 196 |
| HP | CV 25 |
| Hydraulic side shift | O |
| Mechanic side shift | S |
| Angle gear positioned low | S |
| Angle gear 540 revs/min-1 with freewheel | S |
| Groupe multiplicateur 1000 tours /min-1 avec roue libre | n.d. |
| Front version for front PTO 540/1.000 revs/min-1 | n.d. |
| Side runners adjustable in height | O |
| Herbymulching: 100 lt herbicide tank with 12V pump | O |
| Herbymulching: 200 lt herbicide tank with 12V pump | O |
| Overall size - Length | cm 196 |
| Weight (standard version) | kg 540 |
O=Optional - nd=Not available - S=Standard
Download pdf FL 1800
| Working width | cm 205 |
| Number of EM80 double sided blades | 68 |
| Maximum diameter of light wood | cm 1 |
| 3 point linkage ISO | I/II |
| Number of belts | 4 |
| Diameter of height adjustable roller | cm 133 |
| Side shift from middle of tractor | cm 217 |
| HP | CV 30 |
| Hydraulic side shift | O |
| Mechanic side shift | S |
| Angle gear positioned low | S |
| Angle gear 540 revs/min-1 with freewheel | S |
| Groupe multiplicateur 1000 tours /min-1 avec roue libre | n.d. |
| Front version for front PTO 540/1.000 revs/min-1 | n.d. |
| Side runners adjustable in height | O |
| Herbymulching: 100 lt herbicide tank with 12V pump | O |
| Herbymulching: 200 lt herbicide tank with 12V pump | O |
| Overall size - Length | cm 217 |
| Weight (standard version) | kg 700 |
O=Optional - nd=Not available - S=Standard
